Stainless Steel Carbon Steel Explosive Clad Plate For Welding Heavy Industry

Stainless Steel Carbon Steel Explosive Welding Clad Plates For Heavy Industry

Explosive welding Clad metals are a low-resistance, high-strength joint that allows the welding of two dissimilar metals. They are for use in high-current, high-temperature, and mechanical stress environments. The explosive welding creates dissimilar metals into metallurgically bonded. Dissimilar metals are permanently joined for 100% electrical continuity, and demonstrate the characteristics of contiguous metal at the bond interface.

Zigzag bonding                                                Physical binding zone morphology                      Nanoscale ultrafine grain zone

Advantages

• High bonding strength: the energy of explosive explosion makes the base plate(Carbon steel ) impact the clad plate(Stainless steel, Copper, Titanium, etc.) at high speed, generating high temperature and high pressure to achieve solid-phase welding of the interface of the different metals. Ideally, the shear strength of the interface can reach 400Mpa/mm2.
• Multi-metal bonding: Make the different metals to bonding well, even if these metal are in different melting point, strength, thermal expansion coefficient…, such as: aluminum, copper, titanium, stainless steel and other metals.
• The thickness range of clad plate is large.

• Cladding  thickness:2-12mm

  Basement :≥6mm

  Width:＜4000 mm

  Length:＜14000mm

Types of clad plates

Stainless steel  Carbon steel clad plates

Copperaluminum carbon steel clad plates

Aluminum carbon steel clad plates

Titanium carbon steel clad plates

Zirconium carbon steel clad pates

Silver carbon steel clad plates

And other metals.....

Normally series:  ASME standard available for oversea market.
